Model

SOMB-6533A

CPU

Rockchip RK3399 CPU

Graphic Control

Mali-T860@MP4 GPU

Memory

Onboard2GB DDR4 Memory,The biggest can support 4GB

Storage

1*SATA,Support SATA 3.0 1*eMMC,The biggest support 128GB 1*TF

Display Port

1*HDMI,1*MIPI,1* Dual channel 24bit LVDS HDMI up to 4096x2160@60Hz MIPI up to 4096x2160@60Hz Dual channel 24bit LVDS up to 1920x1080@60Hz

Ethernet

2*LAN Realtek RTL8211F,10/100/1000Mbps RJ45 Intel I211,10/100/1000Mbps RJ45 Onboard Wifi Onboard bluetooth

USB

1*USB3.0,7*USB2.0

Audio

1*Headphone,1*MIC-IN,2*5W AMP

COM

5*RS-232,2*RS-232/485

I/O

1*Mini-PCIe(Support 4G module),1*M.2(Support 5G module) 4*GPI,4*GPO

Watchdog

Support

System

Power Supply

DC 12V

Temperature/humidity

Working temperature:0℃～60℃ Storage temperature:-40℃～80℃ 5%～95% Relative humidity,No condensation

Size

155mm x 125mm
